Project overview

Morson Powers specialist power division, Ematics were appointed by The Rosebery Group to provide 11kV Enabling Works for a biomass project at Drax Power Station.

OUR SOLUTION

A new Supervisory Control & Data Acquisition (SCADA) Control System was introduced to allow the control and monitoring of their electrical distribution system including refurbished breakers, new 11kV Biomass Switchboards (11kV incomers, bus couplers and feeders), 11kV/415v step down transformers and 415v Biomass Switchboards (415v feeders switchgear and bus couplers). The electrical systems also included a new essential supplies system including all batteries, chargers and UPS equipment.

The SCADA Control System comprised dual redundant control processors, I/O racks, power supplies and associated hardware in the LV switchroom. Dual SCADA servers, 2 Operator Workstations and 2 Engineer’s Workstations were provided in the Materials Handling Control Room to allow centralised remote monitoring and control of the complete electrical distribution system.

The SCADA Servers communicate with the control processors via a dedicated fast Ethernet fibre optic ring network. There are also interfaces to existing PI Reporting System, iMAC alarm system and Industrial Defender system.

The following systems and services were designed and installed:

  • Schneider PLC Control System
  • Citect SCADA System
  • Fibre Optic Ethernet Architecture
  • ABB Unigear Switchboard
  • Advantys Remote I/O
  • Magelis HMI

Our team added value to the project through:

  • Installation, Testing & Commissioning
  • Flexible Approach
  • Innovative Solutions
  • Value Engineering
  • Compliance with Drax Standards

ABB REF542 Plus Interface:

The control system monitored a number of ABB REF542Plus Intelligent Relays in the electrical Switchrooms via a number of means including Hardwired I/O, Dual Modbus RS485, Modbus TCP/IP and Web Ref Software. The link type used was dependent upon the data being monitored, however the serial interfaces provided a means for collecting time and date stamped data.

Hardwired I/O links were used for a number of new and refurbished Breakers which were connected to the Advantys STB remote I/O units.

Dual Modbus RS485 multi-drop communications networks were used between the Hot Standby Quantum PLCs and the ABB REF542Plus Intelligent Relays on the 11kV Switchboards with the communications arranged such that it is possible to read values via both ports simultaneously thus providing communications redundancy in the event of a cable or network failure.

Modbus TCP/IP Protocol was used for remote communications between the remote I/O PLC’s and the REF542 Plus Relays and were connected to the Main SCADA Fibre Optic Ring Network. All REF542 Plus units were provided with a TCP/IP connection to the Main SCADA Fibre Optic Ring Network. The REF542 Plus Relays each contain a ‘WebRef’ web server interface, this works in conjunction with Ethernet port on REF542 and can be accessed from the Engineers Workstation via Internet Explorer.

Our services

Delivering the project requirements to an agreed Statement of Work (SOW), the Morson Projects team carried out services to include:

  • CAD Drawings
  • Containment System Design
  • Electrical Services
  • Installation
  • Network Infrastructure Design
  • SCADA Systems Integration
  • Site Surveys
  • Software Development
  • System Architecture Design
  • Testing & Commissioning
